8.0MP (4K) NVR for 16 cameras NVH-1652 POE SH with smart functions
)
8.0MP (4K) NVR for 16 cameras with smart functions
Partizan NVH-1652 POE SH.
Smart functions support (available only with SH-series cameras):
- Perimeter Intrusion Detection,
- Line Crossing Detection,
- Stationary Object Detection,
- Pedestrian Detection,
- Face Detection,
- Cross Counting,
- Face Recognition.
Rec speed: 16 channels 8.0Mp@25fps
1xEthernet 10/100/1000Mbit +16x10/100Mbit (PoE). Audio in: 1xRCA. Alarm in: 16
Output: Video out: 1xHDMI, 1xVGA. Audio out: 1xRCA. Alarm out: 1
2xSATA up to 8Tb (not included), 2xUSB 2.0, ONVIF, H.264/H.265, FTP.
Accessories: built-in power adapter DC48V3.75A,mouse
Dimensions: 380x340x50 mm
Software support: Partizan (PC/Android/iOS), Web interface (IE)
Smart Functions: Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Pedestrian Detection, Face Detection, Cross Counting, Face Recognition. Available only with SH-series cameras.
You can connect up to 16 video cameras with a resolution of 8.0Mp (4K) to this multifunctional IP DVR. All the video surveillance channels are recorded simultaneously by the device in real-time mode. Four recording modes – fulltime, alarm, motion or schedule – provide an opportunity to configure the system of video surveillance according to defined tasks within every period of time. The backup to USB storage devices is allowed.
The H.265 codec (high-performance video compression technology) allows you to get a high-resolution video of minimum size (without any quality loss) saving much space on your hard disk. The network managing can be provided from any place of the world. The modern software includes a convenient configurator and a CMS monitoring system. The Ethernet 10/100/1000Base-T network interface provides a reliable, protected connection with the optimal data transfer rate, the maximum value of which is up to 1 Gbit/s.
This model is equipped with the audio input and output for recording and sound playback. The NVR is equipped with a built-in PoE switch for 16 channels (cameras). This allows you to connect each IP camera directly to the NVR with only one Ethernet cable, which simultaneously transmits video and power.
